 系列
Series | 型号
Model
Number | 适用气体
Gas
Service | 流量范围
Delivery Flow LPM | 最大进气压力Max. Inlet Pressure MPa (psi) | 进气螺纹
Inlet
Connection | 出气螺纹
Outlet
Connection | | 191FM | 191FM-25L | 二氧化碳 CO2 | 0-25 | 0.35 (51) | 1/4" NPT (M) | M16-1.5RH (F) | | 系列 | 191FM-25L | 氩气 Ar | 0-25 | 0.35 (51) | 1/4" NPT (M) | M16-1.5RH (F) | | | 191FM-25L | 氦气 He | 0-80 | 0.35 (51) | 1/4" NPT (M) | M16-1.5RH (F) | | | 191FM-50L | 二氧化碳 CO2 | 0-50 | 0.35 (51) | 1/4" NPT (M) | M16-1.5RH (F) | | | 191FM-50L | 氩气 Ar | 0-50 | 0.35 (51) | 1/4" NPT (M) | M16-1.5RH (F) | | | 191FM-50L | 氦气 He | 0-160 | 0.35 (51) | 1/4" NPT (M) | M16-1.5RH (F) | | | 191FM-30L | 氮气 N2 | 0-30 | 0.35 (51) | 1/4" NPT (M) | M16-1.5RH (F) | | | 191FM-30L | 空气 Air | 0-30 | 0.35 (51) | 1/4" NPT (M) | M16-1.5RH (F) | | | 191FM-100L | 氢气 H2 | 0-100 | 0.35 (51) | 1/4" NPT (M) | M16-1.5LH (F) | | 191FM-F | 191FM-25L-F | 二氧化碳 CO2 | 0-25 | 0.35 (51) | M16-1.5RH (F) | M16-1.5RH (F) | | 系列 | 191FM-25L-F | 氩气 Ar | 0-25 | 0.35 (51) | M16-1.5RH (F) | M16-1.5RH (F) | | | 191FM-25L-F | 氦气 He | 0-80 | 0.35 (51) | M16-1.5RH (F) | M16-1.5RH (F) | | | 191FM-50L-F | 二氧化碳 CO2 | 0-50 | 0.35 (51) | M16-1.5RH (F) | M16-1.5RH (F) | | | 191FM-50L-F | 氩气 Ar | 0-50 | 0.35 (51) | M16-1.5RH (F) | M16-1.5RH (F) | | | 191FM-50L-F | 氦气 He | 0-160 | 0.35 (51) | M16-1.5RH (F) | M16-1.5RH (F) | | | 191FM-30L-F | 氮气 N2 | 0-30 | 0.35 (51) | M16-1.5RH (F) | M16-1.5RH (F) | | | 191FM-30L-F | 空气 Air | 0-30 | 0.35 (51) | M16-1.5RH (F) | M16-1.5RH (F) | | | 191FM-100L-F | 氢气 H2 | 0-100 | 0.35 | M16-1.5LH (F) | M16-1.5LH (F) |
|
